FX B.Quiet™️ Single & Worker Acoustic Pod

The FX B.Quiet™️  Single & Worker Acoustic Pods are the perfect solution for providing privacy and confidentiality in today’s modern open plan office. Offering a cost-effective and efficient way to ensure conversations, phone calls and video conferences remain uninterrupted and private, the FX B.Quiet is an excellent addition to any workplace. With a simple & sleek design, the pods fits effortlessly, taking up minimal space and can be relocated when required.

The pods are designed to add both aesthetic appeal and flexibility to the office space, while providing a calm and relaxed work environment. They are sound reducing and equipped with multiple power outlets and air ventilation, making them a comfortable place to work alone or in groups.

Custom order colours and sizes are also available with an 8-10 weeks lead time.

See the PDF of the Mini Catalogue (under Spec Sheet) for further details & options.

 FEATURES:

  • 45mm Hidden Frame Glass Door, 10mm Safety Glass To Rear
  • 6mm Safety Glass To Door Finished With Black Silkscreen Print – Black P/C German Doorware – 3 x Heavy Duty Stainless Steel Hinges
  • Speech Level Reduction: 30DB
  • Acoustic Pod is Fitted With 1 x LED Light 4w 400k – 2 x Ventilation Fan Which Are Controlled By A Door Triggered sensor
  • Power Point: Hager Allure WBHP2SUSBAC-MB – 10Amp Double Internal Powerpoint With USB A+C Charger – Matte Black Bottom Of The Pod Has Been
  • Heavy Duty Castors For Easy Of Movement When Relocating. When Pod Is In Desired Position, Wheel Can Be Retracted And Leveling Feet Take Over
  • Air Replacement: Every 1.2 Minutes ( Total Air Flow: 1340L/Min )
  • 310 Kgs Total Weight Once Assembled
  • 5 Year  Commerical Warranty
  • NOTE:  Stool in Single Pod NOT included & Chair in Work Pod NOT included – please request these as additions

LEAD TIMES:

  • Single Pod – standard colours:  Available ‘off the shelf’- approx 2-4  weeks
  • Single Pod – custom interior & exterior colours:  Approx 8-10 weeks
  • Worker Pod – standard colours:  Approx 8 weeks
  • Worker Pod – custom interior & exterior colours:  Approx 8-10 weeks



Additional information

Size

SINGLE POD:
Overall Size: 2245mm H x 1030mm W x 1030mm D
Internal Size: 2165mm H x 910mm W x 910mm D
Wall Mounted Table: 600mm W x 300mm D ( 2 x 50mm Radius Corners ) D x 25mm T
Doorway width: 840mm

WORKER POD:
Overall Size: 2245mm H x 1615mm W x 1200mm D
Internal Size: 2165mm H x 1495mm W x 1080mm D
Wall Mounted Table: 1074mm W x 615mm D x 25mm T ( Scallop user side – 685mm W x 105mm D )
Doorway Width: 840mm

Standard Colours

REFER to MINI CATALOGUE (under Spec Sheets – Page #10)
Exterior Finish: Black Powdercoat
Interior Finish: GP18 Dark Grey Eco Panel
Desktop Finish: Black Melamine
Carpet Finish: Dark Grey

Custom Colours

REFER to MINI CATALOGUE (under Spec Sheets – Page #14)
*8-10 week approx lead time*

Size:

SINGLE POD:
Overall Size: 2245mm H x 1030mm W x 1030mm D
Internal Size: 2165mm H x 910mm W x 910mm D
Wall Mounted Table: 600mm W x 300mm D ( 2 x 50mm Radius Corners ) D x 25mm T
Doorway width: 840mm

WORKER POD:
Overall Size: 2245mm H x 1615mm W x 1200mm D
Internal Size: 2165mm H x 1495mm W x 1080mm D
Wall Mounted Table: 1074mm W x 615mm D x 25mm T ( Scallop user side – 685mm W x 105mm D )
Doorway Width: 840mm


Standard Colours:

REFER to MINI CATALOGUE (under Spec Sheets – Page #10)
Exterior Finish: Black Powdercoat
Interior Finish: GP18 Dark Grey Eco Panel
Desktop Finish: Black Melamine
Carpet Finish: Dark Grey


Custom Colours:

REFER to MINI CATALOGUE (under Spec Sheets – Page #14)
*8-10 week approx lead time*
